Machines
Flower Sleeves
SDH-800SC
The operation function of this machine can be customized after designing and making it suitable for: Flower bag making machine, Sandwich bag machine.
-
Product features
- - High positioning and sealing cutting accuracy ensured with high quality by servo motor.
- - Automatic positioning when machine stops for added convenience.
- - High accuracy pivot points tracking with high precision photocell sensor.
- - Auto stop if printing points come out of position, minimizes defective product ratio.
- - Variable speed motor allows for speed changes.
- - Employs imported high quality conveyor belt, featuring minimum elongation and a long service life.
- - Quick to change bag shape and size.
- - The machine is ruggedly constructed throughout for maximum stability.
- - Clean, elegant and secure sealing.
- - Easy to operate.
- - Mold changes are quick and easy.
Optional equipment- - Round hole punch.
- - Multi hole punch.
- - Edge positioning controller (EPC).
- - Up & down register device.
- - Wineglass shaped heat sealing Mold.
- - Bottom sealing device.
-
Specifications SDH-800SC W Max. 500 mm A Min. 40 mm L Max. 700 mm Model SDH-800SC Width of Bag 40 - 500 mm Length of Bag 700 mm Speed pc/minute 140 pc Max. Thickness 0.015 ~ 0.08 mm Motor 2 HP Heater 2.5 kW Power Required 5.0 kW Machine Dimensions
(L×W×H)5.6 × 1.6 × 1.8 m Machine Weight 2600 kg Machine Packing
(L×W×H)5.8 × 1.8 × 1.9 m Packing Weight 2900 kg
*Specifications are subject to change without notice.*The machine with servo system the model number will with (NC)
