Home Machines Flower Sleeves SDH-1000SC

Flower Sleeve Machine SDH-1000SC

Inquiry
  • Product features
    • - High positioning and sealing cutting accuracy ensured with high quality by servo motor.
    • - Automatic positioning when machine stops for added convenience.
    • - High accuracy pivot points tracking with high precision photocell sensor.
    • - Auto stop if printing points come out of position, minimizes defective product ratio.
    • - Variable speed motor allows for speed changes.
    • - Employs imported high quality conveyor belt, featuring minimum elongation and a long service life.
    • - Quick to change bag shape and size.
    • - Applicable to the production of plastic conical bag and cone shape bag.
    • - The machine is ruggedly constructed throughout for maximum stability.
    • - Clean, elegant and secure sealing.
    • - Easy to operate.
    • - Mold changes are quick and easy.

    Optional equipment
    • - Round hole punch.
    • - Multi hole punch.
    • - Edge positioning controller (EPC).
    • - Up & down register device.
    • - Wineglass shaped heat sealing Mold.
    • - Bottom sealing device.

    High Quality Production of Custom Flower Sleeves in large Size

    With more than 30 years of experience in side sealing and cutting machine, we can provide comprehensive planning consultation for flower sleeve manufacturing machinery and related equipment. It is recommended that you visit the official YouTube channel of our company. You would be inspired to think about other customized design needs by watching this 1 minute and 50 second video of flower sleeve bag making machine. If you have any suggestions or questions about the video, you can also log in to your account and leave a message to us.

  • Specifications SDH-1000SC
    W Max. 600 mm
    A Min. 40 mm
    L Max. 900 mm

    Model SDH-1000SC
    Width of Bag 40 - 600 mm
    Length of Bag 900 mm
    Speed pc/minute 100 pc Max.
    Thickness 0.015 ~ 0.08 mm
    Motor 2 HP
    Heater 3.5 kW
    Power Required 7.5 kW
    Machine Dimensions
    (L×W×H)
    5.6 × 1.8 × 1.8 m
    Machine Weight 2800 kg
    Machine Packing
    (L×W×H)
    5.8 ×2.0 × 1.9 m
    Packing Weight 3100 kg


    *Specifications are subject to change without notice.

    *The machine with servo system the model number will with (NC)
